Drill Rig Capabilities

• Geotechnical infrastructure borings
• Large diameter augers (up to 12 1/4"")
• Install 6" to 15" diameter wells
• Casing (2" - 18")
• Drive and wash casing
• Rock Coring (2" - 5")
• Down-Hole Air Hammer (2" - 16")
• ODEX drilling capabilities
• Automatic sampling capabilities
• Packer testing
• Quick disconnect tower for low clearances
• Moyno pump equipped 3-L-6 & 3-L-8
• High torque mechanical drive
• On board steam cleaning unit w/ AC power
• Low Clearance Auto Hammer
• Full service ATV off road drilling, both track and rubber tired

Additional Drilling Capabilities

Down-Hole Air Hammers (2" - 10"): For installation of 2" - 10" bedrock wells and the advancement of borings where refusals encountered with augers or casing. Air hammer telescopes down thru casing or augers and penetrates boulders and/or bedrock. Faster than coring or roller bit and is more cost effective than air rotary rigs.​

ODEX Drilling Capabilities: Ideal for setting casing in adverse unconsolidated and bedrock formations where techniques such as mud rotary and conventional air hammer fail, are not practical or are inefficient. ODEX annulus is slightly larger than casing so that the casing can be advanced.

Well Abandonment: Over-drilling & pressure grouting.

Well Development: Waterra, surge blocking, submersible pumps, LDA, DPA and Hydro Frac.
